To purchase parts for the 310AS (Squeegee Assembly):
- Reference the part needed from the parts diagram and refer to the parts list below.
- Copy the Part Number and paste it into the search window above to see availability and pricing.
- Confirm your parts selection and "Add To Cart".
| Item | Part Number | Description | Qty | Item | Part Number | Description | Qty | |
| 1 | SN002 | YOKE, END, M6 | 1 | 37 | RC113 | FITTING, ELBOW, HOSE | 1 | |
| 2 | MI028 | PIN, YOKE, M6, w/ SPRING | 1 | 38 | TB179 | PIPE, ADAPTER, HOSE | 1 | |
| 3 | DD404 | NUT, HEX, M6 | 1 | 39 | GR118 | SEAL, GASKET | 1 | |
| 4 | TI147 | ROD, CONTROL, SOLUTION | 1 | 40 | GH018 | RING, PIPE | 2 | |
| 5 | CP206 | PIN, COTTER, M2 X 30 | 1 | 41 | FS031 | CLAMP, 21-44MM | 1 | |
| 6 | WV010 | SCREW, C. SINK, #10 X 3/8” | 1 | 42 | TB205 | HOSE, SQUEEGEE | 1 | |
| 7 | NB030100 | WASHER, FLAT, #10 | 1 | 43 | RC119 | FITTING, UNION | 1 | |
| 8 | LV063 | LEVER, VALVE | 1 | 44 | VE469 | SCREW, M8 X 60 | 2 | |
| 9 | GH007 | NUT, MOUNTING, VALVE | 1 | 45 | RO404 | WASHER, FLAT, M8 | 2 | |
| 10 | RC074 | FITTING, ELBOW | 1 | 46 | RT155 | COVER, WHEEL | 2 | |
| 11 | RB005 | VALVE, SOLUTION | 1 | 47 | VE443 | SCREW, M6 X 16 | 2 | |
| 12 | RC002 | FITTING, 3/8” NPT X 12MM | 1 | 48 | CO252 | COVER, TRAP, SQUEEGEE | 1 | |
| 13 | FS001 | CLAMP, 8-12MM | 1 | 49 | CP260 | PIN, CLIP, HITCH, M3 | 1 | |
| 14 | TB187 | TUBING, SOLUTION | 1 | 50 | PE167 | PIN, ATTACH, SQUEEGEE | 1 | |
| 15 | CS029 | BEARING, BALL | 1 | 51 | MI171 | LANYARD, CHAIN | 1 | |
| 16 | SN002 | YOKE, END, M6 | 1 | 52 | VC409 | SCREW, M5 X 6 | 1 | |
| 17 | MI028 | PIN, YOKE, M6, w/ SPRING | 1 | 53 | DD405 | NUT, HEX, M8 | 1 | |
| 18 | ML034 | SPRING | 2 | 54 | GR185 | GASKET, COVER, TRAP | 1 | |
| 19 | VI058 | WASHER, 8.5MM | 1 | 55 | VE461 | SCREW, M8 X 20 | 1 | |
| 20 | RO455 | WASHER, LOCK, M8 | 1 | 56 | DD405 | NUT, HEX, M8 | 1 | |
| 21 | VB430 | SCREW, M8 X 16 | 2 | 57 | VL450 | NUT, WING, M6 | 4 | |
| 22 | VE467 | SCREW, M8 X 50 | 2 | 58 | LM631 | BAND, SQUEEGEE, FRONT | 1 | |
| 23 | DD405 | NUT, HEX, M8 | 2 | 59 | BP339 | RUBBER, SQUEEGEE, FRONT | 1 | |
| 24 | SU578 | FRAME, LIFT, SQUEEGEE | 1 | 60 | SQ071 | BODY, SQUEEGEE | 1 | |
| 25 | VE443 | SCREW, M6 X 16 | 1 | 61 | LM632 | BAND, SQUEEGEE, REAR | 1 | |
| 26 | AL093 | AXLE, FRAME, SQUEEGEE | 1 | 62 | BP340 | RUBBER, SQUEEGEE, REAR | 1 | |
| 27 | RT153 | WHEEL, NYLON | 2 | 63 | CC022 | LATCH, SQUEEGEE, REAR | 1 | |
| 28 | PT180 | PLATE, AXLE | 1 | 64 | N/A | N/A | - | |
| 29 | VS421 | SCREW, C.SINK, M6 X 12 | 2 | 65 | KIT859 | SQUEEGEE, ASSEMBLY | 1 | |
| 30 | RO404 | WASHER, FLAT, M8 | 4 | 66 | KIT858 | RUBBER, SQUEEGEE, KIT | 1 | |
| 31 | DD454 | NUT, LOCK, M8 | 2 | 67 | RT154 | WHEEL, 3.94” X 1.2” | 2 | |
| 32 | VB430 | SCREW, SCK HD, M8 X 16 | 2 | 68 | SP001 | PIN, M3 X 16 | 1 | |
| 33 | RO455 | WASHER, LOCK, M8 | 2 | 69 | RO454 | WASHER, LOCK, M6 | 1 | |
| 34 | PT228 | BRACKET, MOUNT, SQUEEGEE | 1 | 70 | TB224 | TUBING, AXLE | 1 | |
| 35 | GH006 | NUT, JAM, ADJUSTMENT, SQ. | 1 | 71 | BO073 | BUSHING, WHEEL | 2 | |
| 36 | VI007 | SCREW, ADJUSTMENT, SQ. | 1 |
